Magnetoresistive one-dimensional induction switch and magnetoresistive two-dimensional induction switch
Magnetoresistive one-dimensional induction switch and magnetoresistive two-dimensional induction switch
Magneto-Resistive Switch Series This series of ICs are manufactured in CMOS or BCD process with integrated Anisotropic Magneto-Resistance (AMR) sensing element. They operate over a variety of supply voltages and offer a variety of sensitivity levels.
Product list
1D AMR Switch
|
Part Number |
Type |
Sampling Frequency (Hz) |
Supply Voltage (V) |
Supply Current |
Temperature Range (℃) |
Magnetic Operating Point (Gs) |
Magnetic Releasing Point (Gs) |
Output Type |
Available Packages |
|---|---|---|---|---|---|---|---|---|---|
| XY6325 | Omni-Polar | 900 | 1.8~5.5 | 4.1uA | -40~125 | ±17 | ±14 | Push pull | DFN1616 |
| XY6325-L | Omni-Polar | 900 | 1.8~5.5 | 4.1 | -40~125 | ±47 | ±38 | Push-pull | DFN1616 |
| XY6341 | Omni-Polar | 20 | 1.8~5.5 | 1.3uA | -40~125 | ±10 | ±8 | Push pull | SOT-23, Flat TO-92 |
| XY6343 | Omni-Polar | 20 | 1.8~5.5 | 1.3uA | -40~125 | ±18 | ±15 | Push pull | SOT-23, Flat TO-92 |
|
Part Number |
Type |
Sampling Frequency (Hz) |
Supply Voltage (V) |
Supply Current (uA) |
Temperature Range (℃) |
Magnetic Operating Point (Gs) |
Magnetic Releasing Point (Gs) |
Output Type |
Available Packages |
|---|---|---|---|---|---|---|---|---|---|
| XY6131 | Omni-Polar | 20 | 1.65~5.0 | 2 | -40~125 | ±18 | ±13 | Push pull | SOT-23 |
| XY6132 | Omni-Polar | 1K | 1.65~5.0 | 15 | -40~125 | ±18 | ±13 | Push pull | SOT-23 |
| XY6133 | Omni-Polar | 20 | 1.65~5.0 | 2 | -40~125 | ±18 | ±13 | Open drain | SOT-23 |
