Mounted Liquid Level Sensor XY-LS600

Hydraulic Liquid Level Transmitter & Gauge With Thread

Mounted liquid level sensor, the mounted liquid level transmitter is based on the principle of hydrostatics to measure the level or water depth,can be used to measure liquid level for Reservoirs, river, sewage treatment, urban water supply, water tank, ocean level and others field need liquid level measurement.

Typical Feature

With Stainless steel 304 shell and 316L diaphragm
With 4-Digits LED Display.
Measurement Range 0~100 Meter
Accuracy level: 0.25% FS; 0.5%FS
Power Supply 9~32VDC, Typical 24VDC
Operating temperature -20℃～80℃
With precision temperature compensation
With protection for Anti-Surge, Over-Voltage, Over-Current and Reversed Polarity

Contact

Brief Introduction
Suggested Applications
Specification
Document
Leave us Message

Mounted Liquid Level Sensor XY-LS600 Brief Introduction

XY-LS600 is a Mounted Liquid Level Sensor, the liquid level sensor is based on the principle of hydrostatics to measure the level or water depth, it has high-performance isolated sensitive components and precision temperature compensation technology to converts the static pressure into an electrical signal, then converts these signals to standard electrical signal output.

They have excellent circuit design to suitable liquid level measurements, such as Anti-Surge, Over-Voltage, Over-Current and Reversed Polarity Protection; with Anti-Electromagnetic Interference function to ensure the output single stably in the complex electromagnetic environment.

The XY-LS600 Mounted Liquid Level Sensor has stainless steel 304 shell and IP68 protection against the harsh service environment, at the same time we test its overload and shock resistance performance in critical test procedure.

It can be wieldy powered by 9-32VDC power supply and output 4-20mA and 0-5VDC single is optional. Accuracy ±0.25%FS; ±0.5%FS. Can be used to measure liquid level for Reservoirs, river, sewage treatment, urban water supply, water tank, ocean level and other field need liquid level measurement.

Suggested Applications

Mounted Liquid Level Sensor XY-LS600 Specification

Model	XY-LS600
Range	0-0.5…1…2…5…8…10…100…200M H2O
Overload Capacity	200%
Measurement Medium	Oil or other Liquid with Compatibility of SS 304 or 316
Supporting	2088 Industrial shell
Accuracy Level	0.25% FS;0.5% FS; Customized higher accuracy
Long-Term Stability/Year	Typical: ±0.1% FS;
Zero Temperature drift	Typical: ±0.02%FS/℃; Maximum ±0.05%FS/℃
Sensitivity Temperature drift	Typical: ±0.02%FS/℃; Maximum ±0.05%FS/℃
Output	4-20mA;0-5V
Electric protection	Short-circuit protection; Reverse connect protection; EMC
Display	4 digits LED
Operating temperature	-20~80oC;-20~120oC is optional
Compensation	-20~80oC
Power Supply	9-32 VDC(Typical 24V)
